Blast Protection products designed for "Class 1 Dangerous Goods"
containment and shipment
THREAT MITIGATION UNITS :
IU 1703 & 1704
Suspect parcels and packages safely contained in seconds
The IU1703 & IU1704 threat mitigation units from Energetics Technology revolutionise the rapid and safe isolation and removal of IED threats in high volume screening situations, often associated with high volume cargo operations. Internally lined with SABREMAT TM.
The primary purpose of these units are the isolation and safe storage of explosive samples whilst present in the laboratory.
A steel fabricated cubic box with perforated steel sides and sliding door (left or right handed).
The door locking mechanism is spring loaded to allow for a single action positive closure, this means that the door may be shut and locked in a single operation.
Both units come fitted with four 150mm diameter pressed steel castors and non-marking treads allowing for low rolling resistance and high abrasion resistance.
The units do not rely on electronic, pneumatic or hydraulic components, preventing unit failure or initiation detonation.
IU 1703 & 1704 Highlights
- Isolation of Explosive samples
- Lockable wheels for stability
- Blast and fragment mitigation
- Full face opening for easy internal access
IU1703 - I Drawer. A single chamber tested with 500g explosives
IU1704 - 2 Drawers. Each with four chambers. Tested with 250gs explosives each. Each drawer is designed to hold four standard H83 / M2A1 Ammunition Containers - eight in total.
CHARACTERISTICS
- Protects people and surroundings from lethal blast effects
- Blast and fragment mitigation – many times the anticipated threat level
- Suspect parcels easily contained in seconds and safely removed for resolution
- Simple operation – easily operated by one person
- Single action self-locking for prompt closure
- Avoids costly evacuations or disruption of business operations
- Lockable wheel for stability
- Full face opening for easy internal access
- No hydraulics, pneumatics or electrics to fail or initiate detonation
- RF shielding properties of up to 20Dd to reduce the chance of remote detonation by mobile phone or Wi-Fi
- Available in a variety of colours and finishes
- Optional logos can be added
| SPECIFICATIONS | IU 1703 | ||
|---|---|---|---|
| External Dimensions (door closed) | H - 1179 mm /46.4 " | Door Open Dimensions | H - 1179mm / 67.3" |
| D - 1164 mm / 45.8" | D - 1164mm / 45.8" | ||
| W - 967 mm / 38.1" | W - 1710 mm / 38.1" | ||
| Total Weight | 1000 Kg / 2200 lbs | ||
| Internal Volume:( A single chamber tested to 500g of explosives) | 1 x 35 litres (9.25 US Gallons) | ||
| 652 X 283mm, H=190mm |
| SPECIFICATIONS | IU 1704 | ||
|---|---|---|---|
| External Dimensions (door closed) | H - 1179 mm /46.4 " | Door Open Dimensions | H - 1179mm / 67.3" |
| D - 1164 mm / 45.8" | D - 1164mm / 45.8" | ||
| W - 967 mm / 38.1" | W - 1710 mm / 38.1" | ||
| Total Weight | 1000 Kg / 2200 lbs | ||
| Internal Volume:(Two drawers with four chambers each. Each tested to 250g explosives each.) | 8 x 10 Litres (2.64 US Gallons) 4 chambers each | ||
| 162.5x322.5mm, H=190mm |
| Product Codes | IU 1703 | IU 1704 |
|---|---|---|
| Left Handed Door | PN02001 | PN02003 |
| Right Handed Door | PN02002 | PN02004 |
