Blast Protection products designed for  "Class 1 Dangerous Goods"

containment and shipment

DETONATOR CONTAINMENT UNIT :
DCU 105/212


Request a Quote

DCU 105/212 Highlights

It is suitable for use by specialised operators and dismounted soldiers and engineers due to its robust, yet lightweight design, enabling the safe transport of single packs of detonators.


The DCU105/212 exhibits extraordinary performance due to Energetic Technologys' patented SABREMATTM technology.


  • Suits a wide variety of detonators. Any detonator other than that tested during trials must be independently tested to get a competent authority approval.
  • Tested to a Max NEQ of 1.0 grams *


(* Tested in Accordance with UN Series 6 (d) test, conducted for specific detonators only.)


CHARACTERISTICS



  • Contains the blast and secondary fragments protecting personnel when carried by hand.
  • Enables detonators and explosives to be stored and transported in the same vehicle
  • Improves logistical options and significantly reduces transport costs
  • Very low maintenance costs
  • Robust hard-wearing unit with nonconductive coating
  • Lightweight and easy to carry by hand
  • Suits a wide variety of detonators
  • Durable and easily cleaned
  • Suitable for belt and rucksack transport
  • Ease of use even with gloved hands





Widely used by NATO, military personnel, EOD teams worldwide and de-mining companies, it also has applications in demolition, quarrying and construction.




SPECIFICATIONS DCU 105/212
External Dimensions Length: 212 mm / 8.27" Internal Dimensions Length: 160 mm / 6.3"
Diameter: 49 mm / 2" Diameter: 25 mm / 1"
Total Weight 400 g / 0.88 lbs
(*All weights and dimensions are approximate)
