The DCU1000 detonator containment unit has been independently tested and is certified to reduce the UN Hazard Classification and compatibility group from 1.1B to 1.4S, making it compliant with road and air transportation regulations and therefore enabling cost effective logistical options (individual competent authority documents required for transport). The DCU1000 is a steel fabricated cubic box with perforated steel sides and full-face opening door. Internally lined with Energetics Technology’s proprietary SABREMATTM materials to the generic cross-sectional configuration. In addition, the core of the unit consists of 16x aluminium modules lined with SABREMATTM . The door locking mechanism is by three individual catches with captive trunnions. The unit does not rely on any electronic, pneumatic or hydraulic components. The function and operation of the DCU1000 can be achieved by a single user.
CHARACTERISTICS
Holds up to 400 detonators with an individual NEQ of 1.49g / 0.05oz
Suitable for most detonators up to a maximum NEQ per chamber of 37.25g / 1.31oz
Can store electric detonators in one chamber and non-electric in another
Takes boxes of detonators up to 360mm / 14.2’’ long (e.g.no.8)
Full face opening for easy front loading of packaged detonators
Easy locking for prompt closing
Vehicle fittings available to use for transport
Durable and easily cleaned
Available in a variety of colours and finishes
Prevents sympathetic detonation
Contains blast and secondary fragments protecting nearby personnel
Very low maintenance costs
Certified with UN Hazard Classification 1.4S.
Slide title
DCU 1000
Button
Slide title
SABREMAT Technology
Button
Slide title
Storing detonators into the DCU 1000 chambers
Button
Slide title
Secondary blast protection
within the DCU 1000
Button
Contains the blast effects and secondary fragments
The DCU1000 detonator containment unit provides blast protection to personnel when storing, handling and transporting bulk quantities of electric and non-electric detonators.
(all weights and dimensions approximate)
Available in a variety of colours and finishes.
SPECIFICATIONS
DCU 1000
External Dimensions
Length:
670 mm / 26"
Internal Dimensions per Chamber
Diameter:
85 mm / 3.3"
Width:
700 mm / 28"
Depth:
for boxes up to : 360 mm / 14.2"
Height:
705 mm / 28"
Total Weight
